Alpine Overhead Doors
Alpine Overhead Doors, Inc. is an innovative, quality driven US-based manufacturer of rolling doors since 1972. Our success is fueled by a passion for designing doors that are built to perform and to last. We are dedicated exclusively to the rolling door market. Our products can be found across the United States and around the world, serving a wide variety of purposes and environmental challenges. Our production facility currently manufactures over 70 different models, and growing. Alpine is a privately held, family owned company based in New York. We follow a made-to-order production process – crafting each door to the customer’s exact size, specifications and requirements. This hands-on, individual design and manufacturing approach to every job ensures customer satisfaction. Simply, we design each door as a “special project” and not as a replicated product. We source the highest quality metals, materials and components only from established, reputable suppliers – those that closely share our mission and vision.
FEMA-Tite™
Product Features:
- Designed, tested and certified as ICC 500-2014/FEMA P-361-2020 rated doors
- Resists flying debris caused by extreme winds
- R-value of 9.00/U-factor of .111
- Certified from (3ft-6in w x 4ft h) up to (20ft w x 14ft h)
- This Smart Security System will close multiple doors upon alarm
Functional Benefits:
- Alpine’s Insulated Metal Backed model FEMA-TITE™ metal on metal insulated slat has polystyrene insulation at a min 15/16” thick with an option for CFC-Free Foamed-in-Place Polyurethane and helps reduce air infiltration.
- A minimum gauge combination of 16ga front slat and 16ga back slat has been missile tested to ensure safety against flying debris.
- Doors are designed to withstand a wind load of 250psf for tornadoes (305psf test at 1.2 times the design pressure)
- Doors are also designed to withstand a wind load of 200psf for hurricanes (305psf at 1.5 times the design pressure)
- “Fail Safe” electric operator which will close the door upon alarm at a rate of 9” per second on average
- All operating systems can be adapted to specific conditions such as; inclement weather, corrosive atmospheres, etc.
- Air infiltration – manufactured to meet 2015. IECC®, ASHRAE®90.1 and California’s Title 24, tested independently to meet 0.3 CFM/FT
- Weather seals consist of a neoprene hood baffle, vinyl guide weather stripping and vinyl astragal on the bottom bar, with an option for 1½” perimeter brush seals
- Not to be mounted to CMU block, filled or hollow.
FEMA-Tite™
Product Features:
- Designed, tested and certified as ICC 500-2014/FEMA P-361-2020 rated doors
- Resists flying debris caused by extreme winds
- R-value of 9.00/U-factor of .111
- Certified from (3ft-6in w x 4ft h) up to (20ft w x 14ft h)
- This Smart Security System will close multiple doors upon alarm
Functional Benefits:
- Alpine’s Insulated Metal Backed model FEMA-TITE™ metal on metal insulated slat has polystyrene insulation at a min 15/16” thick with an option for CFC-Free Foamed-in-Place Polyurethane and helps reduce air infiltration.
- A minimum gauge combination of 16ga front slat and 16ga back slat has been missile tested to ensure safety against flying debris.
- Doors are designed to withstand a wind load of 250psf for tornadoes (305psf test at 1.2 times the design pressure)
- Doors are also designed to withstand a wind load of 200psf for hurricanes (305psf at 1.5 times the design pressure)
- “Fail Safe” electric operator which will close the door upon alarm at a rate of 9” per second on average
- All operating systems can be adapted to specific conditions such as; inclement weather, corrosive atmospheres, etc.
- Air infiltration – manufactured to meet 2015. IECC®, ASHRAE®90.1 and California’s Title 24, tested independently to meet 0.3 CFM/FT
- Weather seals consist of a neoprene hood baffle, vinyl guide weather stripping and vinyl astragal on the bottom bar, with an option for 1½” perimeter brush seals
- Not to be mounted to CMU block, filled or hollow.
